FRAME
aluminium 6061, HD Interface, quick-release 5 x 135mm, disc brake Post Mount
DRIVE UNIT
Bosch Performance CX, 250W, 75Nm, 25km/h
DISPLAY
Bosch Intuvia
BATTERY
Bosch PowerPack, 500 Wh
CHARGER
Bosch quick charger 4A
FORK
SR Suntour NEX E25-LO Lockout, steel spring, Travel: 63mm, steel steerer tube 1 1/8", quick release
SHIFTING SYSTEM
Shimano Alivio M4000, 9 speed
GEAR LEVER
Shimano Alivio M4000, rapidfire
REAR SPROCKET
SunRace CSM980, 11-40 teeth
CHAIN
KMC X9
CHAIN RING
Haibike Components, 16, steel
BRAKE LEVER
Shimano MT200
FRONT BRAKE
Shimano MT200, 180mm, 2-piston disc brake
REAR BRAKE
Shimano MT200, 160mm, 2-piston disc brake
TYRES
Schwalbe Smart Sam, 47-622, 28" x 1.75"
RIMS
Rodi Black Rock 21, with eylets, hollow rim, aluminium
FRONT WHEEL HUB
Shimano TX505
REAR WHEEL HUB
Shimano TX505-8
SPOKES
Sapim Leader, black
HANDLEBAR
Haibike Components TheBar + 720mm
GRIPS
XLC Comfort bo3 with wrist rest
STEM
Haibike Components TheStem +, A-head, Bar bore: 31.8mm, 7˚
HEAD SET
A-Head Tapered, ball bearing
SADDLE
Haibike Components TheSaddle
SEAT POST
Haibike Components The Seatpost +, patent, 31.6mm, aluminium
PEDALS
VP E461 mit Reflektor, aluminium
KICK STAND
Ursus Mooi, adjustable
