FRAME
aluminium 6061, HD Interface, quick-release 5 x 135mm, disc brake Post Mount
DRIVE UNIT
Bosch Performance Cruise, 250W, 60Nm, 25km/h
DISPLAY
Bosch Intuvia
BATTERY
Bosch PowerTube, 500 Wh
CHARGER
Bosch quick charger 4A
FORK
SR Suntour Mobie 45 LOR Lockout, steel spring, Travel: 60mm, aluminium steerer tube 1 1/8" - 1 1/2" tapered, thru-axle
SHIFTING SYSTEM
Shimano Alivio M4000, 9 speed
GEAR LEVER
Shimano Alivio M4000, rapidfire
REAR SPROCKET
SunRace CSM980, 11-40 teeth
CHAIN
KMC e9S
CHAIN RING
Haibike Components, 16, steel
BRAKE LEVER
Magura CMe ABS, aluminium
FRONT BRAKE
Magura CMe 5 ABS, 180mm, aluminium, 4-piston disc brake
REAR BRAKE
Magura CMe ABS, 180mm, aluminium, 2-piston disc brake
TYRES
Schwalbe Road Cruiser, 42-622, 28" x 1.6", Reflective stripes
RIMS
Rodi Black Rock 21, with eylets, hollow rim, aluminium
FRONT WHEEL HUB
Haibike Components TheHub ++ thru-axle 15x100mm
REAR WHEEL HUB
Haibike Components TheHub ++
SPOKES
Sapim Leader, black
HANDLEBAR
Haibike Components TheBar + 720mm
GRIPS
XLC Comfort bo3 with wrist rest
STEM
Haibike Components TheStem +, A-head, Bar bore: 31.8mm, 7˚
HEAD SET
A-Head Tapered, ball bearing
SADDLE
Haibike Components TheSaddle
SEAT POST
Haibike Components The Seatpost +, patent, 31.6mm, aluminium
PEDALS
VP E461 mit Reflektor, aluminium
HEAD LIGHT
Busch & Müller Avy, 40 lux
TAILLIGHT
AXA Blueline
DYNAMO
via system battery
CARRIER
system carrier, XLC Carrymore, max. 25kg
MUDGUARD
SKS, chromoplastics
KICK STAND
Ursus Mooi, adjustable
