Damper
Rockshox, Deluxe Select Plus, Air, 45.0 Mm
-
Frame Family
Haibike, Sduro Fullnine, Aluminium 6061, Thru-Axle M12 (1.75) X 148Mm, Disc Brake Post Mount, Travel= 100 Mm
-
Fork
Sr Suntour, Aion 35 Lo-R, Lockout, Air, Travel= 100 Mm, Aluminium Steerer Tube 1 1/8" - 1 1/2" Tapered, 15 X 110Mm Thru-Axle Boost
-
Rear Derailleur
Sram, Sx Eagle
-
Shift Lever
Sram, Sx Eagle, Trigger Switch, 12 Speed
-
Sprocket
Sram, Eagle Pg1210, 11 - 50 Teeth
-
Bottom Bracket
Integrated In The Motor
-
Crank Arm
Haibike Components, The Crank +, Aluminium
-
Chain
Sram, Sx Eagle
-
Chain Guide
Nylon Directmount
-
Chainring
Sram, 38 Teeth
-
Brake Lever
Tektro, Orion M745, Aluminium
-
Brake Disc (Front)
Tektro, Tr203
-
Brake (Front)
Tektro, Orion M745, 203 Mm, 4-Piston Disc Brake
-
Brake Disc (Rear)
Tektro, Tr180
-
Brake (Rear)
Tektro, Orion M745, 180 Mm, 4-Piston Disc Brake
-
Tube
Presta Valve
-
Tyre
Schwalbe, Nobby Nic Performance, 65-622, 29" X 2.60"
-
Rim (Rear, If Different)
Rodi, Tryp 30, With Eyelets, Hollow Rim, Aluminium
-
Rim
Rodi, Tryp 30, With Eyelets, Hollow Rim, Aluminium
-
Front Wheel Hub
Haibike Components, Thehub ++, 6-Bolt Standard
-
Rear Wheel Hub
Haibike Components, Thehub ++, 6-Bolt Standard
-
Spokes
Sapim, Leader, Black
-
Handlebar
Haibike Components, Thebar ++, 740 Mm
-
Grips
Haibike, Mtb Grips
-
Stem
Haibike Components, Thestem ++, A-Head, Bar Bore: 31.8 Mm, 6°
-
Headset
Feimin, A-Head Tapered, Aluminium, Cartridge Bearing
-
Saddle
Haibike Components, Thesaddle
-
Seat Post
Haibike Components, Theseatpost ++, 31.6 Mm, Aluminium
-
Pedals
Freeridepedal, Aluminium, Mit Reflektor
-
Clamping Ring
Internal Hexagon, 34.9 Mm
-
Engine
Yamaha, Pw-St System, 250 W, 70 Nm, 25 Km/H
-
Weight (Kg)
24.5 Kg
-
Permitted Total Weight
120.0 Kg
-
Battery
Yamaha, Intube, 500 Wh
