Damper
SR Suntour, Raidon LO, Air
Frame Family
Haibike, SDURO FullLife, Aluminium 6061, Thru-axle M12 (1.75) x 142mm, Disc brake Post Mount, Travel= 120 mm
Fork
SR Suntour, XCM32 LO, Steel spring, Travel= 120 mm, Aluminium steerer tube 1 1/8", 15 x 100mm thru-axle
Rear Derailleur
Shimano, Deore M6000
Shift Lever
Shimano, Deore M6000, Rapidfire, 10 speed
Sprocket
Shimano, HG500, 11 - 42 teeth
Bottom Bracket
integrated in the motor
Crank Arm
Haibike Components, The Crank +, Aluminium
Chain
KMC, e10S
Chain Guide
Nylon directmount
Chainring
Steel, 38 teeth
Brake Lever
Tektro, M276, Aluminium
Brake Disc (Front)
Tektro, TR180
Brake (Front)
Tektro, M276, 180 mm, 2-piston disc brake
Brake Disc (Rear)
Tektro, TR180
Brake (Rear)
Tektro, M276, 180 mm, 2-piston disc brake
Tube
Presta valve
Tyre
Schwalbe, Tough Tom, 60-584, 27.5" x 2.35"
Rim (Rear, If Different)
Rodi, Black Rock 23, hollow rim, Aluminium
Rim
Rodi, Black Rock 23, hollow rim, Aluminium
Front Wheel Hub
Haibike Components, TheHub ++, 6-bolt standard
Rear Wheel Hub
Haibike Components, 6-bolt standard
Spokes
Sapim, Leader, black
Handlebar
Haibike Components, TheBar+, 740 mm
Grips
Haibike, MTB grips
Stem
Haibike Components, TheStem +, A-head, Bar bore: 31.8 mm, 7°
Headset
Feimin, A-Head Tapered, ball bearing
Saddle
Haibike Components, TheSaddle Lady
Seat Post
Haibike Components, The Seatpost +, Patent, 31.6 mm, Aluminium
Pedals
Freeridepedal, Aluminium, mit Reflektor
Clamping Ring
Internal hexagon, 34.9 mm
Engine
Yamaha, PW-SE System, 250 W, 70 Nm, 25 km/h
Weight (Kg)
23.8 kg
Permitted Total Weight
120.0 kg
Battery
Yamaha, Lithium Ion, 500 Wh
