Damper
RockShox, Deluxe Select Plus, Air, 65.0 mm
Frame Family
Haibike, SDURO FullSeven LT, Aluminium 6061, Thru-axle M12 (1.75) x 148mm, Disc brake Post Mount, Travel= 150 mm
Fork
SR Suntour, Aion 35 LO-R, Lockout, Air, Travel= 150 mm, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost
Rear Derailleur
Sram, SX Eagle
Shift Lever
Sram, SX Eagle, Trigger switch, 12 speed
Sprocket
Sram, Eagle PG1210, 11 - 50 teeth
Bottom Bracket
integrated in the motor
Crank Arm
Haibike Components, The Crank +, Aluminium
Chain
Sram, SX Eagle
Chainring
Sram, 38 teeth
Brake Lever
Tektro, Orion M745, Aluminium
Brake Disc (Front)
Tektro, TR203
Brake (Front)
Tektro, Orion M745, 203 mm, 4-piston disc brake
Brake Disc (Rear)
Tektro, TR180
Brake (Rear)
Tektro, Orion M745, 180 mm, 4-piston disc brake
Tube
Presta valve
Tyre
Schwalbe, Nobby Nic Performance, 70-584, 27.5" x 2.80"
Rim (Rear, If Different)
Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
Rim
Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
Front Wheel Hub
Haibike Components, TheHub ++, 6-bolt standard
Rear Wheel Hub
Haibike Components, TheHub ++, 6-bolt standard
Spokes
Sapim, Leader, black
Handlebar
Haibike Components, TheBar ++, 740 mm
Grips
Haibike, MTB grips
Stem
Haibike Components, TheStem ++, A-head, Bar bore: 31.8 mm, 6°
Headset
Feimin, A-Head Tapered, Aluminium, cartridge bearing
Saddle
Haibike Components, TheSaddle
Seat Post
Haibike Components, TheSeatpost ++, 31.6 mm, Aluminium
Pedals
Freeridepedal, Aluminium, mit Reflektor
Clamping Ring
Internal hexagon, 34.9 mm
Engine
Yamaha, PW-ST System, 250 W, 70 Nm, 25 km/h
Weight (Kg)
24.6 kg
Permitted Total Weight
120.0 kg
Battery
Yamaha, InTube, 500 Wh
