Frame Family
Haibike, SDURO HardNine, Aluminium 6061, Thru-axle M12 (1.75) x 148mm, Disc brake Post Mount
Fork
SR Suntour, XCM34 LOR, Steel spring, Travel= 100 mm, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost
Rear Derailleur
Shimano, Altus M2000
Shift Lever
Shimano, Altus M2010, Rapidfire, 9 speed
Sprocket
Shimano, HG200, 11 - 36 teeth
Bottom Bracket
integrated in the motor
Crank Arm
Haibike Components, The Crank +, Aluminium
Chain
KMC, X9
Chain Guide
Nylon directmount
Chainring
Steel, 38 teeth
Brake Lever
Tektro, M275, Aluminium
Brake Disc (Front)
Tektro, TR180
Brake (Front)
Tektro, M275, 180 mm, 2-piston disc brake
Brake Disc (Rear)
Tektro, TR180
Brake (Rear)
Tektro, M275, 180 mm, 2-piston disc brake
Tube
Presta valve
Tyre
Schwalbe, Smart Sam Active, 65-622, 28" x 2.60"
Rim (Rear, If Different)
Rodi, Tryp 30, with eyelets, hollow rim, Aluminium
Rim
Rodi, Tryp 30, with eyelets, hollow rim, Aluminium
Front Wheel Hub
Haibike Components, TheHub ++, 6-bolt standard
Rear Wheel Hub
Haibike Components, TheHub ++, 6-bolt standard
Spokes
Sapim, Leader, black
Handlebar
Haibike Components, TheBar+, 740 mm
Grips
Haibike, MTB grips
Stem
Haibike Components, The Stem +, A-head
Headset
Feimin, A-Head Tapered, ball bearing
Saddle
Haibike Components, TheSaddle
Seat Post
Haibike Components, The Seatpost +, Patent, 31.6 mm, Aluminium
Pedals
Freeridepedal, Aluminium, mit Reflektor
Clamping Ring
Quick release, 34.9 mm
Engine
Yamaha, PW-SE System, 250 W, 70 Nm, 25 km/h
Weight (Kg)
24.4 kg
Permitted Total Weight
120.0 kg
Battery
Yamaha, InTube, 400 Wh
