Frame Family
Haibike, SDURO HardSeven Life, Aluminium 6061, Thru-axle M12 (1.75) x 148mm, Disc brake Post Mount
Fork
RockShox, Recon TK, Air, Travel= 130 mm, 15 x 110mm thru-axle Boost
Rear Derailleur
Sram, SX Eagle
Shift Lever
Sram, SX Eagle, Trigger switch, 12 speed
Sprocket
Sram, Eagle PG1210, 11 - 50 teeth
Bottom Bracket
integrated in the motor
Crank Arm
Haibike Components, The Crank +, Aluminium
Chain
Sram, SX Eagle
Chain Guide
Nylon directmount
Chainring
Sram, 38 teeth
Brake Lever
Tektro, Orion M745, Aluminium
Brake Disc (Front)
Tektro, TR180
Brake (Front)
Tektro, Orion M745, 180 mm, 4-piston disc brake
Brake Disc (Rear)
Tektro, TR180
Brake (Rear)
Tektro, Orion M745, 180 mm, 4-piston disc brake
Tube
Presta valve
Tyre
Schwalbe, Smart Sam Active , 65-584, 27.5" x 2.60"
Rim (Rear, If Different)
Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
Rim
Rodi, Tryp 35, with eyelets, hollow rim, Aluminium
Front Wheel Hub
Haibike Components, TheHub ++, 6-bolt standard
Rear Wheel Hub
Haibike Components, TheHub ++, 6-bolt standard
Spokes
Sapim, Leader, black
Handlebar
Haibike Components, TheBar ++, 740 mm
Grips
Haibike, MTB grips
Stem
Haibike Components, TheStem ++, A-head, Bar bore: 31.8 mm, 6°
Headset
Feimin, A-Head Tapered, Aluminium, cartridge bearing
Saddle
Haibike Components, TheSaddle
Seat Post
Haibike Components, The Seatpost +, Patent, 31.6 mm, Aluminium
Pedals
Freeridepedal, Aluminium, mit Reflektor
Clamping Ring
Quick release, 34.9 mm
Engine
Yamaha, PW-ST System, 250 W, 70 Nm, 25 km/h
Permitted Total Weight
120.0 kg
Battery
Yamaha, InTube, 500 Wh
