Frame
28", ultra lite AL-6061 tubing, PowerTube battery
Fork
Suntour Mobie 45 Air, RLR DS, 80 mm, 15x100 mm axle
E.Drive System
Motor: Bosch Drive Unit Performance Line Speed, Gen. 4, 250 W, 36 V, max. 45 km/hDisplay: Bosch KioxBattery: Bosch 36 V Li Ion, 625 Wh, PowerTubeAssistance Modes: Eco (+60%), Tour (+140%), eMTB (+140 - 340%), Turbo (+340%), Walk Assist (-5 km/h)
Rear Derailleur
Shimano Deore XT, RD-M8100, Shadow Plus
Shifters
Shimano Deore, SL-M6100, 1x12-speed, rapidfire plus-shifter
Crankset
FSA CK-320, 42t
BB-Set
Bosch, Isis
Chain
KMC e12S
Cassette
Shimano Deore, CS-M6100, 10-51t
Brake Levers
Magura MT5e (front) Magura MT4e (rear), hydraulic disc brake
Brakes
Magura MT5e (front) /Magura MT4e (rear), hydraulic disc brake, Storm HC rotor: 203/180 mm
Handlebar
BGM Pro, riserbar, backsweep: 15°, rise: 5 mm
H'stem
BGM E-Bike, adjustable, for Kiox integration
Seatpost
BGM Pro
Seat
Ergon ST10
Headset
FSA NO.57SC-1, A-Headset, semi-integrated, tapered
Hub (Front)
Shimano HB-MT400, centerlock, disc, 15x100 mm axle
Hub (Rear)
Shimano FH-MT401, centerlock, disc, quick release
Spokes
Sapim Leader
Rims
Ryde Rival 23, disc, eyelets
Tires
Schwalbe Marathon E-Plus, Smart Dual Guard, reflective stripe, 47-622Tubes: Schwalbe SV19B Light
Lights
Front: B&M IQ-X-E, 150 Lux, LED, E-Bike VersionRear: B&M LED, with brakelight
Rack & Fenders
Fender: Racktime WingeeCarrier: Racktime / BGM Trekking Pro, integrated fender mount
Pedals
Syncros Trekking alloy
Accessories
Kickstand: Syncros
Approx weights in KG
25,6
Color
black/blue dust (shiny/matt)
Frame size
44/48/52/56 cm
Chain cover
SKS Chainbooster
Grips
Ergon GP10
Max. System Weight
140 kgThe overall weight includes the bike, the rider, the equipment and possible additional luggage.
