Frame
29", ultra lite AL-6061 tubing, integrated PowerPack battery
Fork
Suntour XCR32, 100 mm, rebound adjust
E.Drive System
Motor: Bosch Drive Unit Performance Line Cruise, Gen. 3, 250 W, 36 V, max. 25 km/hDisplay: Bosch PurionBattery: Bosch 36 V Li Ion, 500 Wh, PowerPack, coveredAssistance Modes: Eco (+55%), Tour (+120%), eMTB (+120 - 300%), Turbo (+300%), Walk Assist (-5 km/h)
Rear Derailleur
Shimano RD-M2000, Shadow
Shifters
Shimano SL-M3100, 1x9-speed, rapidfire plus-shifter
Crankset
FSA CK-200, 32t, 170 mm
BB-Set
Bosch, Isis
Chain
KMC e9S
Cassette
Sunrace CS-M90, 11-36t
Brake Levers
Shimano BL-MT200, hydraulic disc brake
Brakes
Shimano BR-MT200, hydraulic disc brake, SM-RT10 rotor: 180/180 mm
Handlebar
Syncros 3.0, riserbar, rise: 15 mm, width: 740 mm / 720 mm for size S
H'stem
Syncros 3.0, +/-6°
Seatpost
Syncros M3.0
Seat
Syncros M3.0
Headset
FSA NO.57SC-1, A-Headset, semi-integrated, tapered
Hub (Front)
Shimano, centerlock, disc, quick release
Hub (Rear)
BGM Pro, centerlock, disc, 12x148 mm axle
Spokes
Sapim Leader
Rims
Ryde Rival 23, disc, eyelets, width: 23 mm
Tires
Maxxis Rekon, 29x2.40"Tubes: Impac SV29
Pedals
none
Approx weights in KG
22,5
Color
radiant blue/black (shiny/matt)
Frame size
S/M/L/XL
Grips
Syncros MTB
Max. System Weight
135 kgThe overall weight includes the bike, the rider, the equipment and possible additional luggage.
