Frame
29", ultra lite AL-6061 tubing, PowerTube battery
Fork
Suntour Raidon 34, 100 mm, 15x110 mm axle
E.Drive System
Motor: Bosch Drive Unit Performance Line CX Cruise, Gen. 4, 250 W, 36 V, max. 25 km/hDisplay: Bosch KioxBattery: Bosch 36 V Li Ion, 625 Wh, PowerTubeAssistance Modes: Eco (+60%), Tour (+140%), eMTB (+140 - 340%), Turbo (+340%), Walk Assist (-5 km/h)
Rear Derailleur
Shimano Deore XT, RD-M8100, Shadow Plus
Shifters
Shimano Deore XT, SL-M8100, 1x12-speed, rapidfire plus-shifter
Crankset
FSA CK-745, 34t, 170 mm
BB-Set
Bosch, Isis
Chain
KMC e12 EPT
Cassette
Shimano SLX, CS-M7100, 10-51t
Brake Levers
Shimano BL-MT401, hydraulic disc brake
Brakes
Shimano BR-MT420, hydraulic disc brake, 4-piston, SM-RT30 rotor: 203/180 mm
Handlebar
Syncros Hixon 2.0, mini riserbar, rise: 15 mm, width: 740 mm / 720 mm for size S
H'stem
Syncros FL2.0, +/-6°
Seatpost
Syncros M3.0
Seat
Ergon SM10 E-Mountain
Headset
BGM F13-X, A-Headset, semi-integrated, tapered
Hub (Front)
Shimano HB-MT400-B, centerlock, disc, 15x110 mm axle
Hub (Rear)
Shimano FH-MT510-B, centerlock, disc, 12x148 mm axle
Spokes
Sapim Leader
Rims
Alex EXR25, disc, eyelets, width: 25 mm
Tires
Maxxis Crossmark II, EXO, folding, Tubeless ready, 29x2.25"Tubes: Schwalbe SV21B
Lights
Front: Litemove SE, 110 Lux, LED, E-Bike VersionRear: Herrmans H-Trace Mini, LED
Rack & Fenders
Fender: Racktime WingeeCarrier: New Racktime / BGM carrier
Pedals
none
Accessories
Kickstand: Syncros
Approx weights in KG
23,6
Color
dark petrol/black/gold (matt)
Frame size
S/M/L/XL
Grips
Ergon GA20
Max. System Weight
135 kgThe overall weight includes the bike, the rider, the equipment and possible additional luggage.
