Frame
29", ultra lite AL-6061 tubing, PowerTube battery
Fork
Suntour XCM34, 100 mm, rebound adjust, 15x110 mm axle
E.Drive System
Motor: Bosch Drive Unit Performance Line CX Cruise, Gen. 4, 250 W, 36 V, max. 25 km/hDisplay: Bosch PurionBattery: Bosch 36 V Li Ion, 625 Wh, PowerTubeAssistance Modes: Eco (+60%), Tour (+140%), eMTB (+140 - 340%), Turbo (+340%), Walk Assist (-5 km/h)
Rear Derailleur
Shimano Deore, RD-M5100, Shadow Plus
Shifters
Shimano Deore, SL-M5100, 1x11-speed, rapidfire plus-shifter
Crankset
FSA CK-320, 34t, 170 mm
BB-Set
Bosch, Isis
Chain
KMC e11S
Cassette
Shimano Deore, CS-M5100, 11-51t
Brake Levers
Shimano BL-MT201, hydraulic disc brake
Brakes
Shimano BR-MT200, hydraulic disc brake, SM-RT30 rotor: 180/180 mm
Handlebar
Syncros 3.0, riserbar, rise: 15 mm, width: 740 mm / 720 mm for size S
H'stem
Syncros 3.0, +/-6°
Seatpost
Syncros M3.0
Seat
Syncros Savona 2.5
Headset
FSA NO.57SC-1, A-Headset, semi-integrated, tapered
Hub (Front)
Shimano HB-MT400-B, centerlock, disc, 15x110 mm axle
Hub (Rear)
Shimano FH-MT400-B, centerlock, disc, 12x148 mm axle
Spokes
Sapim Leader
Rims
Alex EXR30, disc, eyelets, width: 30 mm
Tires
Maxxis Rekon, EXO, 29x2.60"Tubes: Impac SV29
Pedals
none
Approx weights in KG
23,6
Color
flaky turquoise/black (matt)
Frame size
XS/S/M/L
Grips
Syncros MTB
Max. System Weight
135 kgThe overall weight includes the bike, the rider, the equipment and possible additional luggage.
