Frame
29", ultra lite AL-6061 tubing, PowerTube battery, 150 mm rear travel
Fork
RockShox 35 Silver, 160 mm, air, 15x110 mm axle
Rear Shock
X-Fusion 02 Pro RLX, 3 position compression adjustment, rebound
E.Drive System
Motor: Bosch Drive Unit Performance Line CX Cruise, Gen. 4, 250 W, 36 V, max. 25 km/hDisplay: Bosch PurionBattery: Bosch 36 V Li Ion, 625 Wh, PowerTubeAssistance Modes: Eco (+60%), Tour (+140%), eMTB (+140 - 340%), Turbo (+340%), Walk Assist (-5 km/h)
Rear Derailleur
Shimano Deore XT, RD-M8100, Shadow Plus
Shifters
Shimano Deore, SL-M6100, 1x12-speed, rapidfire plus-shifter
Crankset
FSA CK-320, 34t, 165 mm
BB-Set
Bosch, Isis
Chain
KMC e12S
Cassette
Shimano Deore, CS-M6100, 10-51t
Brake Levers
Shimano BL-MT401, hydraulic disc brake
Brakes
Shimano BR-MT420, hydraulic disc brake, 4-piston, SM-RT30 rotor: 203/203 mm
Handlebar
Syncros Hixon 2.0, riserbar, rise: 12 mm, width: 780 mm
H'stem
Syncros FL2.0, +/-6°
Seatpost
Syncros Duncan 2.5, dropper post, 150 mm (frame size "S": 125 mm), remote
Seat
Syncros Tofino 2.5
Headset
BGM F13-X, A-Headset, semi-integrated, tapered
Hub (Front)
Shimano HB-MT400-B, centerlock, disc, 15x110 mm axle
Hub (Rear)
Shimano FH-MT410-B, centerlock, disc, 12x148 mm axle
Spokes
Sapim Leader
Rims
Alex EXR30, disc, eyelets, width: 30 mm
Tires
Front: Schwalbe Magic Mary Evo, folding, Addix Soft, 29x2.60"Rear: Schwalbe Hans Dampf Evo, folding, Addix Soft, 29x2.60"Tubes: Schwalbe SV19FB Light
Pedals
none
Approx weights in KG
25,1
Color
flaky reed-gold/black (matt)
Frame size
S/M/L/XL
Grips
Ergon GA20
Max. System Weight
135 kgThe overall weight includes the bike, the rider, the equipment and possible additional luggage.
