Frame
28", lite AL-6061 tubing, PowerTube battery
Fork
Suntour Mobie 25 Air, RLR DS, 100 mm, 15x100 mm axle
E.Drive System
Motor: Bosch Drive Unit Performance Line CX Cruise, Gen. 4, 250 W, 36 V, max. 25 km/hDisplay: Bosch KioxBattery: Bosch 36 V Li Ion, 625 Wh, PowerTubeAssistance Modes: Eco (+60%), Tour (+140%), eMTB (+140 - 340%), Turbo (+340%), Walk Assist (-5 km/h)
Rear Derailleur
Shimano Deore XT, RD-M8100, Shadow Plus
Shifters
Shimano Deore, SL-M6100, 1x12-speed, rapidfire plus-shifter
Crankset
FSA CK-745, 38t
BB-Set
Bosch, Isis
Chain
KMC e12S
Cassette
Shimano Deore, CS-M6100, 10-51t
Brake Levers
Shimano Alfine, BL-S7000, hydraulic disc brake
Brakes
Shimano Alfine, BR-S7000, hydraulic disc brake, SM-RT54 rotor: 180/160 mm
Handlebar
BGM Pro, riserbar, backsweep: 15°, rise: 5 mm
H'stem
BGM E-Bike, adjustable
Seatpost
BGM Pro
Seat
Selle Royal Lookin BGM Basic Athletic
Headset
Acros, A-Headset, semi-integrated, 1.5", with intergrated cable routing
Hub (Front)
Shimano HB-MT400, centerlock, disc, 15x110 mm axle
Hub (Rear)
Shimano FH-MT401, centerlock, disc, quick release
Spokes
Sapim Leader
Rims
Ryde Rival 23, disc, eyelets
Tires
Schwalbe Marathon E-Plus, Smart Dual Guard, reflective stripe, 55-622Tubes: Schwalbe AV19
Lights
Front: B&M IQ XS, 70 Lux, LED, E-Bike VersionRear: B&M Bergamont Special LED, with brake light
Rack & Fenders
Fender: BGM special alloy, with stainless staysCarrier: Racktime E-Ville carrier
Pedals
Trekking alloy
Accessories
Kickstand: Syncros
Approx weights in KG
27,8
Color
black/silver (matt/shiny)
Frame size
46/50/54/58 cm
Grips
BGM Comfort, Ergo, double density, clamp version
Max. System Weight
160 kgThe overall weight includes the bike, the rider, the equipment and possible additional luggage.
