FRAME
CRAFTY STEALTH AIR FULL CARBON, E-BIKE OPTIMIZED ZERO SUSPENSION SYSTEM, 150MM TRAVEL, FORWARD GEOMETRY, INTERNAL NON-REMOVABLE BATTERY, BOOST 12X148MM REAR AXLE, TAPERED HEAD TUBE, ONE-PIECE MONOBLOCK UPPER LINK, HHG INTERNAL CABLE ROUTING, MAX CAPACITY SEALED BEARINGS, OVERSIZE 17MM AXLES, INTEGRATED DROPOUT SPEED SENSOR, EXCLUSIVE PLASTIC MOTOR COVERS
SIZES
S: 380MM / M: 420MM / L: 450MM / XL: 490MM
REAR SHOCK
ÖHLINS TTX AIR 205X65MM. SETTINGS: HIGH SPEED COMPRESSION LEVER WITH CLIMB MODE, LOW-SPEED COMPRESSION, REBOUND, AIR PRELOAD. TRUNNION TOP MOUNT, 25X10MM BOTTOM BUSHINGS
SHOCK SETTINGS
C40 COMPRESSION, R60 REBOUND
FORK
ÖHLINS RXF 38 29, 170MM, TTX18 TWIN TUBE CARTRIDGE, TAPERED STEERER TUBE, BOOST 15X110MM AXLE, OFFSET 44MM. SETTINGS: HIGH SPEED COMPRESSION LEVER WITH CLIMB MODE, LOW-SPEED COMPRESSION, REBOUND, AIR PRELOAD, RAMP CHAMBER
HEADSET
ACROS CUSTOM FOR 1-1/2" HEAD TUBE, ANGULAR CONTACT BEARINGS 40X52X7, INTERNAL CABLE ROUTING
STEM
ONOFF KRYPTON FG 30MM, 6061 FORGED ALLOY, 31.8MM BARBORE
HANDLEBAR
ONOFF KRYPTON CARBON 1.0, RISE: 25MM, WIDTH: 780MM, 9° BACKSWEEP, 5° UPSWEEP, 31.8MM BARBORE
GRIPS
ONOFF DESERT, 1LOCK-ON, 135MM, SIZES: S/M L/XL
SEATPOST
ONOFF PIJA DROPPER INTERNAL, DIAMETER 31.6MM, S SIZE: 387X125MM, M SIZE: 425X150MM, L/XL SIZE: 465X170MM
SADDLE
FIZIK ANTARES R7
FRONT BRAKE
SRAM CODE RSC, OVERSIZED 4-PISTON CALIPER, CENTERLINE 200MM IS 6 BOLTS ONE-PIECE ROTOR, STEELBACKED METAL SINTERED PADS
REAR BRAKE
SRAM CODE RSC, OVERSIZED 4-PISTON CALIPER, CENTERLINE 200MM IS 6 BOLTS ONE-PIECE ROTOR, STEELBACKED METAL SINTERED PADS
BRAKE LEVER
SRAM CODE RSC, SWINGLINK AND LEVER PIVOT BEARINGS, TOOLS-FREE REACH AND CONTACT POINT ADJUST
RIMS
DT SWISS HX1501 SPLINE ONE 29, 30MM INTERNAL WIDTH, WELDED ALUMINUM, TUBELESS READY, 28 SPOKES
SPOKES
DT HYBRID SP, STRAIGHTPULL
FRONT HUB
DT 240, BOOST 15X110MM, IS 6 BOLTS
REAR HUB
DT 240, BOOST 12X148MM, 24T RATCHET SYSTEM, IS 6 BOLTS
FRONT TYRE
MAXXIS MINION DHF 29X2.6, TUBELESS READY, 3C MAXX TERRA, EXO+ PROTECTION, 120TPI, FOLDING BEAD
REAR TYRE
MAXXIS MINION DHR II 29X2.6, TUBELESS READY, 3C MAXX TERRA, EXO+ PROTECTION, 120TPI, FOLDING BEAD
CRANKSET
E.13 E*SPEC PLUS EBIKE, 165MM
CHAINRING
SRAM X-SYNC 2 EAGLE 34T, STEEL, NARROW-WIDE, 104 BCD
BOTTOM BRACKET
---
PEDALS
---
CHAIN
SRAM NX EAGLE, 12S, POWERLOCK
FRONT DERRAILLEUR
---
REAR DERRAILLEUR
SRAM X01 EAGLE, TYPE 3 ROLLER BEARING CLUTCH, CAGE LOCK, 1X12S, X-ACTUATION 1:1
SHIFT LEVERS
SRAM TRIGGER GX EAGLE, 12S, X-ACTUATION 1:1, SINGLE CLICK
CASSETTE
SRAM XG-1275, 10-52T, 12S
MOTOR
BOSCH PERFORMANCE LINE CX CRUISE (25KM/H) GEN4
BATTERY
BOSCH POWERTUBE 625WH
DISPLAY
BOSCH KIOX
DERAILLEUR HANGER
MONDRAKER M068
