Frame
Alpha Platinum Aluminium, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, magnesium rocker link, Motor Armour, Mino Link, ABP, Boost148, 12 mm thru axle, 150 mm travel
-
Fork
RockShox Yari RC, DebonAir spring, Motion Control RC damper, e-MTB optimised, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 160 mm travel
-
Shock
RockShox Deluxe RL, 230x57.5 mm
-
Front Wheel
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle
-
Rear Wheel
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
-
Tire
Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29x2.60"
-
Shifter
Shimano SLX M7100, 12-speed
-
Rear Derailleur
Shimano XT M8100, long cage, 51T max cog
-
Crank Arm
E*thirteen E*spec Plus, 34T, 165mm length
-
Cassette
Shimano SLX M7100, 10-51, 12-speed
-
Chain
Shimano SLX M7100, 12-speed
-
Pedal
VP-536 nylon platform
-
Saddle
Bontrager Arvada, steel rails, 138 mm width
-
Seatpost
Size: S
TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length
Size: M, L, XL
TranzX JD-YSP18, 130mm travel, internal routing, 31.6 mm, 425 mm length
-
Handlebar
Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 780mm width
-
Grips
Bontrager XR Trail Comp, nylon lock-on
-
Stem
Bontrager Rhythm Comp, 31.8mm, Knock Block, 0-degree, 50 mm length
-
Brake
Shimano MT520 4-piston hydraulic disc
-
Battery
Bosch PowerTube 625
-
Controller
Bosch Purion
-
Motor
NEW Bosch Performance Line CX, 250 Watt, 75Nm, magnesium body, 25 km/h max assist
-
Weight
M - 23.65 kg / 52.14 lbs (with tubes)
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
