Merida's most versatile full suspension bike running 130mm forks with plush 120mm rear travel.
Merida's most versatile full suspension bike running 130mm forks with plush 120mm rear travel.
Merida

2021 Merida One-Twenty 400 Mountain Bike in Orange

€1,963.62
EUR
£1,700.00
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

2021 Merida One-Twenty 400 Mountain Bike in Orange

Season:2021

Brand:Merida

Code:P-M010

Merida's most versatile full suspension bike running 130mm forks with plush 120mm rear travel.

The designers considered both riders and mechanics, delivering a playful modern trail bike with a slack head angle, low stand over height and short chain stays thats easy to maintain. All key bolts can be adjusted from one side of the bike with a torx 30 key without the need for removing the chain set to access the main pivot bolt.

Features:
  • Supple 120mm rear travel with air shock and 130mm SR XCR 34 front air fork
  • Shimano Deore 1 x 11 drivetrain
  • Shimano boost standard centrelock hubs
  • Shimano hydraulic disc brakes
  • €1,963.62
    EUR
  • $2,845.41
    AUD
  • $2,648.05
    CAD
  • $3,305.63
    NZD
  • $1,908.06
    USD
  • CHF1,522.04
    CHF
  • kr21,021.64
    SEK
  • kr240,228.22
    ISK
  • kr14,672.85
    DKK
  • kr19,237.25
    NOK
  • ¥303,006.29
    JPY
  • Technical Information
    • Frame
      Lite 6066 series triple butted, hydroformed aluminium tubing with smooth welding. Tapered head tube, Boost axle standard for stronger wheels, Smart Entry cable clamping for rattle free running.
    • Rear Shock
      Suntour Unair TR LOR8; lockout
    • Fork
      Suntour XCR34 LOR; Air; 130mm travel; Tapered; lockout; 51mm fork offset
    • Headset
      FSA NO.47/50
    • Stem
      Merida Expert CC; aluminium; 31.8mm diameter; -6 degree rise - Length : 60 mm all sizes
    • Handlebar
      Merida Expert CC; aluminium; 740mm wide; 10mm rise
    • Grip
      Merida Comp EC
    • Brake Type
      Hydraulic disc
    • Brake Lever
      Shimano BR-MT200 (or Tektro HD-M275 if Shimano supply is delayed)
    • Brake Calipers
      Front: Shimano BR-MT200 (or Tektro HD-M275) hydraulic brake caliper with Shimano RT10; 180mm rotor Rear: Shimano BR-MT200 (or Tektro HD-M275) hydraulic brake caliper with Shimano RT10; 180mm rotor
    • Tyres
      Front: Maxxis Rekon; 29 x 2.4; wire bead Rear: Maxxis Rekon; 29 x 2.4; wire bead
    • Wheel Size
      29
    • Wheels
      Rims: Merida Comp CC; 20mm inner rim width; Material: aluminium Spokes: Black stainless Front Hub: Shimano MT400-B; 110x15mm; 32 spokes; Centerlock Rear Hub: Shimano MT400-B; 148x12mm; 32 spokes; Centerlock; including removable lever with 4/6mm Allen key
    • Rear Derailleur
      Shimano Deore M5100 Shadow+
    • Shift Levers
      Shimano Deore M5100
    • Chain
      KMC X11 NPBK
    • Cassette
      Shimano Deore M5100; 11-51 teeth; 11 speed
    • Chainset
      Shimano Deore M5100; 32 teeth chainwheel with 170mm - S, 175mm - M up length crank
    • Bottom Bracket
      Shimano MT500-PA pressfit
    • Pedals
      Not included
    • Saddle
      Merida Comp CC
    • Seat Post
      Merida Comp TR; 30.9mm diameter; in-line; S: 100mm drop - M: 125mm drop - L/XL: 150mm drop with Shimano SL -MT500-IL lever
