Frame
Alpha Platinum Aluminium, tapered head tube, Knock Block, Control Freak internal routing, downtube guard, ISCG 05, magnesium rocker link, Mino Link, ABP, Boost148, 130 mm travel
-
Fork
Size: XS , S
RockShox Recon RL, Solo Air spring, Motion Control damper, tapered steerer, 46mm offset, Boost110, 15mm Maxle Stealth, 140mm travel
Size: S , M , ML , L , XL , XXL
RockShox Recon RL, Solo Air spring, Motion Control damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 140 mm travel
-
Shock
Size: XS , S
RockShox Deluxe Select+, 210x52.5mm
Size: S , M , ML , L , XL , XXL
RockShox Deluxe Select Plus, 210x55 mm
-
Front Hub
Formula DC-511, 6-bolt, Boost110, 15 mm thru axle
-
Rear Hub
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Shimano 8/9/10 freehub, Boost148, 12 mm thru axle
-
Rim
Alex MD35, Tubeless Ready, 32-hole, 35 mm width, Presta valve
-
*Tire
Size: XS , S
Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 27.5x2.60"
Size: S , M , ML , L , XL , XXL
Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 29x2.60"
-
Shifter
Shimano Deore M6000, 10-speed
-
Rear Derailleur
Shimano Deore M6000, mid cage, 42T max cog
-
Crank
Size: XS , S
Race Face Ride, 30T steel ring, Boost, 170 mm length
Size: M , ML , L , XL , XXL
Race Face Ride, 30T steel ring, Boost, 175 mm length
-
Bottom Bracket
Shimano MT500, 92 mm, PressFit
-
Cassette
SunRace, 11-42, 10-speed
-
Chain
KMC X10, 10-speed
-
Saddle
Bontrager Arvada, steel rails, 138 mm width
-
Seatpost
Size: XS , S
TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length
Size: M , ML , L , XL , XXL
TranzX JD-YSP18, 130mm travel, internal routing, 31.6 mm, 425 mm length
-
Handlebar
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
-
Grips
Bontrager XR Trail Comp, nylon lock-on
-
Stem
Bontrager Rhythm Comp, 31.8mm, Knock Block, 0-degree, 50 mm length
-
Brake
Shimano MT200 hydraulic disc
-
Weight
M - 15.03 kg / 33.14 lbs (with tubes)
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
