Frame
Alpha Platinum Aluminium, internal storage, tapered head tube, Knock Block 2.0, Control Freak internal routing, down tube guard, shuttle guard, threaded BB, ISCG 05, 34.9 mm seat tube, magnesium rocker link, Mino Link, ABP, Boost148, 160 mm travel
Fork
RockShox Yari RC, DebonAir spring, Motion Control RC damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 170 mm travel
Shock
RockShox Deluxe Select+, DebonAir spring, Select+ RL damper, 230x62.5 mm
Front wheel
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle
Rear wheel
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Shimano 8/9/10 freehub, Boost148, 12 mm thru axle
Rear skewer
Bontrager Switch thru axle
Tyre
Size: S/M/ML/L/XL, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29x2.40"
Size: S/M/ML/L/XL, Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29x2.60"
Tyre part
Bontrager TLR valve, 50 mm
Shifter
SRAM NX Eagle, 12-speed
Rear derailleur
SRAM NX Eagle
Crank
Size: S, SRAM X1 Eagle, DUB, 30T steel ring, Boost (55 mm chain line), 170 mm length
Size: M/ML/L/XL, SRAM X1 Eagle, DUB, 30T steel ring, Boost (55 mm chain line), 175mm length
Cassette
SRAM PG-1230 Eagle, 11-50, 12-speed
Chain
SRAM NX Eagle, 12-speed
Saddle
Bontrager Arvada, hollow chromoly rails, 138 mm width
Seatpost
Size: S, TranzX JD-YSP39, 100 mm travel, internal routing, 34.9 mm
Size: M/ML, TranzX JD-YSP39, 150 mm travel, internal routing, 34.9 mm
Size: L/XL, TranzX JD-YSP39, 170 mm travel, internal routing, 34.9 mm
Handlebar
Bontrager Line, alloy, 35 mm, 27.5 mm rise, 820 mm width
Stem
Bontrager Line, 35 mm, Knock Block, 0-degree, 40 mm length
Head set
Knock Block 2.0 Integrated, 72-degree radius (includes infinite-radius chip), sealed cartridge bearing, 1-1/8" top, 1.5" bottom
Brake
SRAM Guide T hydraulic disc
Brake rotor
Size: S/M/ML/L/XL, SRAM CenterLine, 6-bolt, round-edge, 180mm
Size: S/M/ML/L/XL, SRAM CenterLine, 6-bolt, round-edge, 200 mm
Bag
Bontrager BITS Internal Frame Storage Bag
Weight
M - 15.08 kg / 33.25 lbs (with tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
