Mainframe
OCLV Mountain Carbon main frame and stays, IsoStrut, tapered head tube, Knock Block, Control Freak internal routing, Boost148, 60 mm travel
-
Fork
RockShox SID Ultimate, Solo Air spring, Motion Control damper, TwistLoc dual remote, tapered carbon steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 100 mm travel
-
Shock
Trek IsoStrut, Fox Factory shock, air spring, DPS 2-position remote damper, Kashima Coat, 235x32.5 mm
-
Front Wheel
Bontrager Kovee XXX 30, OCLV Mountain Carbon, Tubeless Ready, CenterLock, Boost110, 15 mm thru axle
-
Rear Wheel
Bontrager Kovee XXX 30, OCLV Mountain Carbon, Tubeless Ready, DT Swiss 54T engagement, CenterLock, SRAM XD driver, Boost148, 12 mm thru axle
-
Tire
Bontrager XR1 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29x2.20"
-
Shifter
SRAM Eagle AXS, wireless, 12-speed
-
Rear Derailleur
SRAM XX1 Eagle AXS
-
Crank
Size: S
SRAM XX1 Eagle AXS Carbon, DUB, 34T alloy ring, Boost, 170mm length
Size: M, M/L, L, XL, XXL
SRAM XX1 Eagle AXS Carbon, DUB, 34T alloy ring, Boost, 175 mm length
-
Bottom Bracket
SRAM DUB, 92 mm, PressFit
-
Cassette
SRAM XG-1299 Eagle, 10-50, 12-speed
-
Chain
SRAM XX1 Eagle, 12-speed
-
Saddle
Bontrager Montrose Pro, 7x10 mm carbon rails, 138 mm width
-
Handlebar
Bontrager Kovee XXX, OCLV Carbon, 35 mm, 0 mm rise, 720 mm width
-
Grips
ESI Chunky
-
Stem
Size: S
Bontrager Kovee Pro, 35 mm, Knock Block, Blendr-compatible, 0-degree, 60 mm length
Size: M, M/L
Bontrager Kovee Pro, 35 mm, Knock Block, Blendr-compatible, 0-degree, 70 mm length
Size: L, XL
Bontrager Kovee Pro, 35 mm, Knock Block, Blendr-compatible, 0-degree, 80 mm length
Size: XXL
Bontrager Kovee Pro, 35 mm, Knock Block, Blendr-compatible, 0-degree, 90 mm length
-
Brake
SRAM Level Ultimate hydraulic disc, carbon levers
-
Weight
M - 9.40 kg / 20.73 lbs
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
