Frame
100 Series Alpha Aluminium, hidden mudguard mounts, DuoTrap S-compatible, 130x5 mm QR
-
Fork
Domane carbon, straight alloy steerer, mudguard mounts, 5x100 mm QR
-
Front Hub
Formula TK-31 alloy, 5x100 mm QR
-
Rear Hub
Formula TK-32 alloy, Shimano 8/9/10 freehub, 5x130 mm QR
-
Rim
Bontrager Tubeless Ready, 24-hole, 17 mm width, Presta valve
-
Spokes
14 g aero stainless steel
-
Tire
Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x28 c
-
Shifter
Shimano Claris R2000, 8-speed
-
Front Derailleur
Shimano Claris R2000, 31.8 mm clamp
-
Rear Derailleur
Shimano Claris R2000, long cage, 34T max cog
-
*Crank
Size: 47
Shimano RS200, 50/34 (compact), 165 mm length
Size: 50, 52, 54, 56
Shimano RS200, 50/34 (compact), 170 mm length
-
Bottom Bracket
Shimano UN26, 68 mm, threaded cartridge, 110 mm spindle
-
Cassette
Shimano HG31, 11-32, 8-speed
-
Chain
Shimano Sora HG71, 8-speed
-
Pedal
Wellgo nylon body, alloy cage
-
Saddle
Bontrager Ajna Comp Gel, hollow chromoly rails, 154 mm width
-
*Seatpost
Size: 47, 50
Bontrager alloy, 27.2 mm, 12 mm offset, 250 mm length
Size: 52, 54, 56
Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length
-
*Handlebar
Size: 47
Bontrager Comp VR-S, alloy, 31.8 mm, 81 mm reach, 118 mm drop, 36 cm width
Size: 50
Bontrager Comp VR-S, alloy, 31.8 mm, 81 mm reach, 118 mm drop, 38 cm width
Size: 52, 54
Bontrager Comp VR-S, alloy, 31.8 mm, 81 mm reach, 118 mm drop, 40 cm width
Size: 56
Bontrager Comp VR-S, alloy, 31.8 mm, 81 mm reach, 118 mm drop, 42 cm width
-
Handlebar Tape
Bontrager Supertack Perf tape
-
*Stem
Size: 47
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
Size: 50
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Size: 52, 54
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
Size: 56
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length
-
Headset
FSA Integrated, sealed cartridge bearing, 1-1/8"
-
Brake
Alloy dual-pivot
-
Weight
52 - 9.84 kg / 21.7 lbs
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
